電源システム

GZDW-25/220

仕様
―仕様―
◆ Standard design :GZDW33
◆ Main wire connection type:Single wire connection
◆ System capacity :25A、220V
◆ Shelf mode :charging and feeding cabinet+batteries
◆ Module installation::1 to 4 unit(XPRM-22005B)
◆ Monitoring installation:AC、DC,module and monitoring system
◆ Output control channel:8 channels with 20A
◆ Close gae output channel:6 channels with 125A
◆ Input channel :2 channels with 380V AC
◆ Voltage regulation :one set (20A 7V X 5)
◆ Flashing equipment:one set(flashing requency 60 circle per minutes)
◆ Insulation monitoring :one set
ページトップへ

GZDW-50/220

仕様
―仕様―
◆ Standard design :GZDW33
◆ Main wire connection type:Single wire connection
◆ System capacity :50A、220V
◆ Shelf mode :charging and feeding cabinet+batteries
◆ Module installation::1 to 4 unit(XPRM-2212A)
◆ Monitoring installation:AC、DC,module and monitoring system
◆ Output control channel:8 channels with 20A
◆ Close gae output channel:6 channels with 125A
◆ Input channel :2 channels with 380V AC
◆ Voltage regulation :one set (20A 7V X 5)
◆ Flashing equipment:one set(flashing requency 60 circle per minutes)
◆ Insulation monitoring :one set
ページトップへ

GZDW-120(90)/220

仕様
―仕様―
◆ System capacity :120A(90A)
◆ Shelf mode :charging and feeding cabinet+batteries
◆ Module installation::1 to 6 unit(XPRM-22020B)
◆ Monitoring installation:AC、DC,module and monitoring system
◆ Output control channel:8 channels with 10A , 4 channels with 20A
◆ Close gae output channel:4 channels with 20A , 4 channels with 80A
◆ Voltage regulation :one set (20A 7V X 5)
◆ Flashing equipment:one set(flashing requency 60 circle per minutes)
◆ Insulation monitoring :one set
主に---220KV、330KV変電所、小さい水力発電所と50MW小型の火力発電所に応用します
ページトップへ

GZDW-240(180)/220

仕様
―仕様―
◆ System capacity :240A(180A)
◆ Shelf mode :charging and feeding cabinet+batteries
◆ Module installation::1 to 12 unit(XPRM-22020B)
◆ Monitoring installation:AC、DC,module and monitoring system
◆ Output control channel:8 channels with 20A , 16 channels with 10A
◆ Close gae output channel:16 channels with 63A , 8 channels with 20A
◆ Voltage regulation :one set (20A 7V X 5)
◆ Flashing equipment:one set(flashing requency 60 circle per minutes)
◆ Insulation monitoring :one set
主に---500KV変電所、小さい水力発電所と200MW小型の火力発電所に応用します
